High performances book mounting IPC based on Intel Skylake H and Kaby Lake H platforms

The fanless Book Mounting IPC family BM3400 is based on the 6th generation Core i3, i5, i7 and Celeron of the Intel® Skylake™ H and the BM3600 family is based on the 7th generation Core i3, i5, i7 of the Intel® Kaby Lake™ H platform. The systems are supplied with a sturdy aluminum chassis, highly refined in every aesthetic and ergonomic detail.The 'all in one' motherboard provides, on. The Asia-Europe Meeting (ASEM) is the major political platform linking Europe and Asia. Its 53 partner countries represent 60% of the world’s GDP, more than 60% of the world’s population and around 55% of global trade. GUWAHATI, Jan 30: Miscreants on Thursday stole a car from the city after sedating the driver. According to the family members of the driver of the vehicle, Nayan Moni Deka, a group on that day hired the car from Hatigaon area and then intoxicated the driver by mixing some sedatives with food. Drivers A lot is riding on your choice of auto repair shops. ASE is here to help you make your best decision. You probably already have an auto technician you know and trust.

The fanless Book Mounting IPC family BM3400 is based on the 6th generation Core i3, i5, i7 and Celeron of the Intel® Skylake™ H and the BM3600 family is based on the 7th generation Core i3, i5, i7 of the Intel® Kaby Lake™ H platform. The systems are supplied with a sturdy aluminum chassis, highly refined in every aesthetic and ergonomic detail.


The 'all in one' motherboard provides, on top, four Ethernet 10/100/1000Mbps ports, that support 'Jumbo Frame' and 'Wake on Lan' functionalities, two USB 3.0 ports, two USB 2.0 ports, a serial RS232 interface and one DVI-D video output; on front, a USB 3.0 port, a SATA III CFast slot, a slot for the extractable system battery, the signalling LEDs and optionally two slots for extractable storage units drawers.


The motherboard has also an mSATA connector for a SATA III SSD, two SATA III connector for 2.5' SSD/HDDs, the possibility to set the mass storage devices in RAID 0, 1 configuration, up to 32 GB RAM with two DDR4 SODIMM modules and an internal connector for additional interfaces, including serial, USB and remotation of the video and USB signals up to 100m (Remote Video Link).


BM3400 and BM3600 systems have an isolated 24 VDC power supply input and optionally an integrated UPS with external battery pack.


The systems are available in two versions, the S0 with the possibility to install additional interfaces and the S2 with two PCI or PCIe expansion slots. Optionally a forced ventilation kit is available to ensure 0°C÷50°C operating temperature with Core i7 processor or expansions cards with total power consumption not grater than 20W.

Technical Data


Intel® Celeron G3900E 2.40GHz 64bit, 2 cores / 2 threads, 2MB Smart cache

Intel® Core i3-6100E 2.70GHz 64bit, 2 cores / 4 threads, 3MB Smart cache
Intel® Core i5-6440EQ 2.70GHz (3.40GHz Turbo) 64bit, 4 cores / 4 threads, 6MB Smart cache
Intel® Core i7-6820EQ 2.80GHz (3.50GHz Turbo) 64bit, 4 cores / 8 threads, 8MB Smart cache

Intel® Core i3-7100E 2.90GHz 64bit, 2 cores / 4 threads, 3MB Smart cache

Intel® Core i5-7440EQ 2.90GHz (3.60GHz Turbo) 64bit, 4 cores / 4 threads, 6MB Smart cache
Intel® Core i7-7820EQ 3.00GHz (3.70GHz Turbo) 64bit, 4 cores / 8 threads, 8MB Smart cache

Intel® HM170 PCH (Platform Controller Hub)

Intel® HM175 PCH (Platform Controller Hub)

Intel® CM236 PHC (Platform Controller Hub)

Intel® HD Graphics 510 integrated in Celeron processor ▪ 350MHz/950MHz ▪ DirectX 12 and OpenGL 4.4 support

Intel® HD Graphics 530 integrated in Core i3 processor ▪ 350MHz/950MHz ▪ DirectX 12 and OpenGL 4.4 support
Intel® HD Graphics 530 integrated in Core i5, Core i7 processors ▪ 350MHz/1,00GHz ▪ DirectX 12 and OpenGL 4.4 support

Intel® HD Graphics 630 integrated in Core i3 processor ▪ 350MHz/950MHz ▪ DirectX 12 and OpenGL 4.5 support

Intel® HD Graphics 630 integrated in Core i5, Core i7processors ▪ 350MHz/1,00GHz ▪ DirectX 12 and OpenGL 4.5 support

4GB (1 x SODIMM DDR4 module) or 8GB or 16GB or 32GB (2 x SODIMM DDR4 modules)

TPM module (optional)

1 bootable CFast SATA III slot onboard with external access
1 x onboard connector for direct insertion of mSATA SSD SATA III
Drivers Asem
without RVL: onboard connectors for 1 x SSD/HDD 2.5' SATA III with internal installation kit or max 2 x SSD/HDD 2.5' SATA III with front extractable drawers with RVL: onboard connector for 1 x SSD/HDD 2.5' SATA III with internal installation kit or with front extractable drawer
Asem

onboard connectors for max 2 x SSD/HDD 2.5' SATA III with internal installation kit or with front extractable drawers

4 x LAN 10/100/1000Mbps top (RJ45 - 3 x Intel® I210 + 1 x Intel® I219LM)

Drivers

1 x USB 3.0 front (Type-A)

2 x USB 2.0 top (Type-A) + 2 x USB 3.0 top (Type-A)

1 x RS232 (DB9M)

1 x CR2032 Removable front access

Drivers Asem

1 x DVI-D, top

1 or 2 x RJ45 connectors Remote Video Link (DVI-D and USB 2.0 signals remotation up to 100 m, optional)

Position A

  • 1 x RS232/422/485 (DB15M) isolated + 1 x USB 2.0 (Type-A)

  • 2 x RS232 (DB9M)

  • 2 x USB 2.0 (Type-A)

  • 1 x NETcore X fieldbus boards for EtherCAT, EtherNet IP, PROFINET, PROFIBUS, CANopen protocols

Position B


  • 2 x connectors Remote Video Link (RJ45 - RVL OUT)

2 x PCIe x4 or 1 x PCI + 1 x PCIe x4 (5 Gb/s), max 10W total

Forced ventilation kit for 0°C÷50°C operating temperature with Core i7 processors or expansion card with max 20W total

24VDC (18÷32VDC) isolated with UPS (optional) with external battery pack

Aluminium Alloy 6082/5754/5056

Microsoft Windows 7 Pro/Ultimate 32/64bit (BM3400)

Microsoft Windows Embedded Standard 7E/7P 32/64 bit (BM3400, WES7E not for TFM)
Microsoft Windows 8.1 Industry Pro 32/64bit, (BM3400)

Drivers Assessment Fee

Microsoft Windows 10 IoT Enterprise 2016 64bit (BM3400 / BM3600)
  • without forced ventilation: 0°C÷50°C, 0°C÷45°C with HDD 24x7 or Core i7

  • with forced ventilation: 0°C÷50°C, 0°C÷45°C with HDD 24x7

CE, cULus LISTED (61010)

Asem

Asem Drivers

Personal area

Login to your personal area to download your restricted contents. If you don’t have am ASEM account yet, register here.

Drivers Assessment Form

  • ACPI_driverInstaller.exe(3.69 MB)
  • ASEM_UPS_Console_v.2.8_Setup.exe(382.35 KB)
  • Driver_ASEM_SkyLake_KabyLake_Win10-64_1607.zip(402.69 MB)
  • Driver_ASEM_SkyLake_KabyLake_Win10-64_1809.zip(473.13 MB)
  • Driver_ASEM_SkyLake_KabyLake_Win7_32.zip(205.24 MB)
  • Driver_ASEM_SkyLake_KabyLake_Win7_64.zip(346.91 MB)
  • Driver_ASEM_SkyLake_KabyLake_Win_8.1-64.zip(338.71 MB)
  • ReadMe.txt(2.71 KB)
  • TAG_driverInstaller.exe(677.13 KB)

Drivers Assessment Michigan

  • BM3400 S0.pdf(314.91 KB)
  • BM3400 S2.pdf(469.61 KB)
  • BM3600 S0.pdf(312.15 KB)
  • BM3600 S2.pdf(313.43 KB)
